Redefining Product Decoration

Since 1985, Engineered Printing Solutions has worked with market leaders to build industrial print machinery with custom automation for product-line integration.

See the Possibilities

Explore Our Products & Custom Solutions

Not sure where to get started?

Tell us what you’re looking for by answering a few quick questions about your requirements.

Applications Industries Digital Printers Pad Printing Machines Engineering & Automation Contact Us

Custom Engineering & Automation

Innovative engineering and automation solutions designed to streamline workflows, boost efficiency, and elevate your production capabilities.

Get Started with a Custom Solution.

Printing Equipment

Explore Our Printers

Lorem ipsum dolor sit amet consectetur adipiscing elit semper dalar elementum tempus hac tellus libero accumsan. Not sure where to start?
Let’s work on this together—Contact Us.

  • XD Linear (XD1)

    High-Speed automated single pass technology built for scale based on print swath and print heads.

    Precision engineering meets custom flexibility

    • Print widths of 70 mm, 108 mm, 140 mm, or 210 mm
    • CMYK+WW print heads, varnish heads available
    • Extended Color Gamut (CMYK+OGV) available
    • Four levels of greyscale
    • Corona, Flame, or Plasma Pretreatment available
    • Drop-on-demand InstaCure UV ink allows printing multiple colors with zero down time Multi-color printing in a single pass
    • Product height and width 12 inches
    • 4- color integrated RIP available with variable image data
    • Fine lines and details at 14 inches per second @ 360 dpi
    • Continuous circulating ink management system
    • Automatic parts handling, pretreatment and vision system options available
    View Series Details

  • Cylindrical Multipass DualSpin

    Store artwork for rapid changeovers. Direct-to-object rotational inkjet printing equipment for everything from drinkware to industrial parts.

    Print Direct

    • Seamless 360 degree printing
    • Ink Droplet Conversion Algorithm realizes consistent resolutions and stable visual effects in different objects.
    • Ink Droplet Compensation Algorithm for taper printing prevents image deformation.
    • Automatic ink system recirculates ink and monitors levels
    • Programmable maintenance schedule allows automatic purging, wiping, and capping of print heads
    • 2 X 2 operation: stations move in and out of machine for continuous printing
    • Print four parts 170 mm x 230 mm image at 600 x 900 DPI W+CMYK+V in just 38 seconds in production mode
    View Series Details

  • FlatBed Mulitpass FJET

    UV Flatbed printers are also known as scanning printers, because the printheads move back and forth while building the specified resolution across the object to be printed.

    UV-LED flatbed inkjet printer combining reliability, stability and versatility

    • Best for flat to semi-flat materials.
    • Maximum print area 24″ x 20″.
    • Platen height adjustment up to 6″.
    • System includes dedicated PC installed with ColorPrint RIP software.
    • Drop-on-demand UV-LED ink with rapid curing.
    • High-opacity whites.
    • Large 1.5 liter ink tanks for each color.
    • Clear coat available.
    • Automatic print head maintenance.
    View Series Details

  • XDR

    Multi-surface prints in single cycle on 3-dimension objects with a multi-directional print head which can jet ink up to 17mm away from target.

    Revolutionize Your Industrial Printing with the XDR

    • 70mm, 140mm and 210mm print width, infinite length.
    • 360dpi, single pass, grayscale.
    • Max robot reach of 3 meters.
    • Fanuc industrial robot.
    • Print speeds up to 6in/s on curved or large surfaces.
    • Liquid UV curable inks.
    • Self-contained ink system with bulk refill.
    • Built in distance/object detection.
    • Job & Print Queue Management for local and remote diagnostics.
    • Beckhoff Industrial PC with standard HMI interface.
    • Remote customer interface.
    • Typical Power Requirements: 240VAC, 50/60Hz, 3 phase, 20A.
    View Series Details

  • EAZY Pad Printers

    The series EAZY identifies easier to use pad printing machines which do not require special maintenance.

    The EAZY Series of pad printing machines features a large-diameter cup at an affordable price.

    • Electro-pneumatic control
    • Micrometrical and adjustable fixture support table
    • Photopolymer, steel, and laser plate capability
    • Sliding left and right side guard protection
    • Foot pedal included
    • Adjustable steel dovetail pad assembly
    View Series Details

  • Electronic Pad Printers

    We have several high-speed servo-driven pad printers for use in existing or new production lines. Controls can be mounted in the front or the back of the machine.

    Electronic Pad Printing machines are equipped with brushless motors

    View Series Details

  • Electropneumatic Pad Printers

    Pneumatic control offers similar function to servo-driven pad printing machines, usually at a lower price.

    Electropneumatic pad printing machines for all printing needs

    View Series Details

  • XD Linear (XD1)

    High-Speed automated single pass technology built for scale based on print swath and print heads.

    Precision engineering meets custom flexibility

    • Print widths of 70 mm, 108 mm, 140 mm, or 210 mm
    • CMYK+WW print heads, varnish heads available
    • Extended Color Gamut (CMYK+OGV) available
    • Four levels of greyscale
    • Corona, Flame, or Plasma Pretreatment available
    • Drop-on-demand InstaCure UV ink allows printing multiple colors with zero down time Multi-color printing in a single pass
    • Product height and width 12 inches
    • 4- color integrated RIP available with variable image data
    • Fine lines and details at 14 inches per second @ 360 dpi
    • Continuous circulating ink management system
    • Automatic parts handling, pretreatment and vision system options available
    View Series Details

Looking for a fully custom solution? We can do that! Tell us about your printer needs.

Request a Quote

About Us

About EPS & What Makes You Unique

Customization & Innovation

EPS specializes in providing precision-engineered printing solutions that cater to a range of industries with complex, custom printing needs.

Quality & reliability

EPS is focused on delivering high-quality, reliable printing solutions, emphasizing attention to detail and robust technology.

Customer-Centric Approach

We aim to provide tailored solutions and a high level of customer support to ensure the best outcomes for clients.

About EPS Our Engineering Process

  • What our clients say

    “When we bring new projects to the EPS team, we are confident that the appropriate process will be identified and validated through testing. We will have the resources available to properly quote the job, define the process and communicate effectively with our customer.”
    John Schwartz
    Schwartz Brothers Printing

What’s New

Stay up to date on EPS innovations, product launches, technical insights, and company updates.

View all news.
